Vertical Eco Flat
RAL 9016
DOUBLE PANEL – NO CONVECTORS
CODE
HEIGHT
WIDTH
C/C TAPPINGS
WATTS
BTU's
LIST PRICE
DMV318
1800
300
245
649
2205
£734.43
DMV418
1800
400
345
865
2941
£837.03
DMV518
1800
500
445
1081
3676
£944.47
DMV618
1800
600
545
1297
4412
£1051.96
DMV320
2000
300
245
730
2482
£774.67
DMV420
2000
400
345
974
3311
£888.48
DMV520
2000
500
445
1217
4138
£1010.38
DMV620
2000
600
545
1461
4964
£1132.19
Outputs at Delta T50°C
Vertical Eco Flat Wall to Centre of tapping
DOUBLE 80mm
Click here for larger image

10 YEAR WARRANTY


Horizontal Eco Flat
Singles Type 11 P+ Type 21 Doubles Type 22
Code Height Width Watts BTUs Price Code Height Width Watts BTUs Price Code Height Width Watts BTUs Price
SM305 300 500 235 803 271.45 DM305 300 500 450 1536 354.00
SM310 300 1000 469 1604 398.82 DM310 300 1000 899 3072 560.42
SM314 300 1400 656 2240 503.5 DM314 300 1400 1259 4301 737.09
SM320 300 2000 937 3207 626.97 DM320 300 2000 1799 6145 966.79
SM404 400 400 242 827 271.03 DM404 400 400 461 1575 350.16
SM406 400 600 363 1240 315.56 DM406 400 600 691 2362 425.59
SM408 400 800 484 1654 373.69 DM408 400 800 922 3149 520.54
SM410 400 1000 606 2068 432.39 DM410 400 1000 1152 3936 615.75
SM412 400 1200 727 2481 501.62 DM412 400 1200 1382 4724 722.29
SM414 400 1400 848 2895 555.28 DM414 400 1400 1613 5511 812.16
SM416 400 1600 969 3309 617.93 DM416 400 1600 1844 6298 911.63
SM418 400 1800 1090 3722 654.27 DM418 400 1800 2075 7085 984.84
SM420 400 2000 1211 4135 703.59 DM420 400 2000 2305 7872 1051.37
SM504 500 400 294 1006 297.83 DM504 500 400 556 1899 395.33
SM506 500 600 442 1508 350.88 DM506 500 600 835 2850 486.81
SM508 500 800 589 2011 421.2 DM508 500 800 1112 3800 603.00
SM510 500 1000 736 2513 492.96 DM510 500 1000 1391 4751 720.00
SM512 500 1200 883 3017 576.43 DM512 500 1200 1669 5699 848.3
SM514 500 1400 1030 3519 640.36 DM514 500 1400 1947 6649 957.55
SM516 500 1600 1178 4022 701.82 DM516 500 1600 2226 7607 1065.26
SM518 500 1800 1325 4524 761.96 DM518 500 1800 2503 8550 1170.16
SM520 500 2000 1472 5028 822.9 DM520 500 2000 2782 9504 1275.94
SM604 600 400 345 1178 318.38 DM604 600 400 647 2207 436.73
SM606 600 600 517 1766 381.26 PM606 600 600 771 2633 468.33 DM606 600 600 969 3311 545.82
SM608 600 800 690 2355 463.39 PM608 600 800 1028 3511 586.65 DM608 600 800 1292 4414 683.83
SM610 600 1000 862 2944 545.73 PM610 600 1000 1285 4388 707.53 DM610 600 1000 1616 5517 821.09
SM612 600 1200 1035 3534 613.62 PM612 600 1200 1542 5266 824.96 DM612 600 1200 1939 6621 970.39
SM614 600 1400 1207 4122 714.38 PM614 600 1400 1799 6144 951.63 DM614 600 1400 2262 7725 1099.89
SM616 600 1600 1379 4711 786.54 DM616 600 1600 2585 8828 1227.25
SM618 600 1800 1552 5299 815.19 DM618 600 1800 2908 9931 1351.88
SM620 600 2000 1724 5889 882.43 DM620 600 2000 3231 11034 1477.84
Outputs at Delta T50°C
Click for larger image
